Quail Cages H-Type 5 Tier

H-Type 5 Tier pullet, broiler and layer cages for quail

Automatic Poultry House for Broilers

  • Automatic Feeding Line

  • Automatic Drinking Line

  • Silo

  • Cooling System

  • Heating System

  • Climate Control

Description

Quail cage is widely used for baby quails(pullet), broiler (meat production) and egg layer (egg production) quail. Its material made from steel wire mesh with hot dipped galvanized.

Cages Drinking System

  • High-quality suck nipple, no water leaking.

  • High-quality water pipe 22mm x 22mm.

  • Reasonable design, the amount of water can be adjusted completely according to the water requirements of quails. As a result, the manure is dry and convenient to move, ensuring a good environment for the quail house.

  • The height of young quail cages water pipe can be adjusted according to the growth of quail.

  • Medicine can be added to the drinking system through the water tank.

  • Flush valve at the end of each line.



Cages Feeding System

  • Hot-dipped galvanized material making.

  • Each row has an independent feeding line, easy to operate and the maintenance rate is very low.

  • Automatic power feeding system can reduce labor.



Cages Manure Removal System

  • Hot-dipped galvanized scraper with nylon blade, the durability is more than 5 years, without rust.

  • The material of the conveyor belt is imported corrosion protection PE transformation.

  • Transporting the quail manure to the truck directly, ensuring the good environment of the quail house.

Classification of H-Type Cages depending on the usage

Pullet Cages

  • Pullet cages are designed with mesh flooring 8mm x8mm.

  • Each cage consists of 4 number of nipple drinker unit inside the cage adjustable height.

  • Manual Feeding system attached to the front door (removable).

  • Inside cage manual PVC drinker.

  • Inside cage manual round feeder.

  • PE manure belt with options of manual rotation or automatic gearbox motor cleaning.

  • Nylon manure belt scraper with spring tension.

  • Water tank with float equipped with each tier.



Broiler Cages

  • Broiler cages are designed with mesh flooring 12mm x12mm.

  • Each cage consists of 4 number of nipple drinker unit inside the cage adjustable height.

  • Manual Feeding system attached to the front door with an adjustable opening (removable).

  • PE manure belt with options of manual rotation or automatic gearbox motor cleaning.

  • Nylon manure belt scraper with spring tension.

  • Water tank with float equipped with each tier.



Layer Cages

  • Layer cages are designed with mesh flooring 12mm x12mm.

  • Each cage consists of 6 number of nipple drinker unit, fixed outside the cage on the rear door.

  • Manual Feeding system attached to the front door (removable).

  • Egg collection under the feeder with egg opening of 32mm height.

  • PE manure belt with options of manual rotation or automatic gearbox motor cleaning.

  • Nylon manure belt scraper with spring tension.

  • Water tank with float equipped with each tier.



Specifications

Dimensions

  • Overall Length              100 cm (each cage of 5 tier)

  • Overall Height              180 cm

  • Overall Width               70 cm

  • Tier to tier                     30 cm

  • Tier height                    25 cm

  • Tier width                     55 cm

  • Tier length                   100 cm

  • Drive side                     58cm x 35cm x 180cm (manual)

                                             58cm x 40cm x 180cm (automatic, heights point 220cm)

  • Roll back                       58cm x 20cm x 180cm(manual)

                                             58cm x 25cm x 180cm (automatic, highest point 220cm)

Automatic




























​​​

Manual















Connections

  • Power supply             1ph 220VAC or 3ph 380VAC , 50-60Hz

  • Water supply              ½”  BS fitting

  • Water discharge        1” PVC socket for each tier





(Note: All dimensions subject to change without notice)
